Hydrophilic Coated Guidewire
Product Features
● Hydrophilic coating guide wire has good flexibility and is not easy to bend.
● The hydrophilic coated layer is good lubricity, easy to insert smoothly.
● For non-cardiovascular surgery and urological surgery.
● Includes radiopaque tips for visibility under fluoroscopy or X-ray imaging.
● Made from nitinol material, providing strength and flexibility.
Material and structure
● Nitinol core wire +PU jacket + hydrophilic coating(PVP).
Instruction for use
● Inspect packaging for sterility and expiry.
● Gather equipment (guidewire, introducer sheath, imaging tools, saline/heparin solution).
● Prep the patient and establish access.
● Activate the hydrophilic coating by immersing the guidewire in saline or heparinized solution.
● Insert introducer sheath or catheter.
● Insert the guidewire and advance it gently under imaging guidance.
● Navigate to the target site, avoiding excessive force.
● Use the guidewire to deliver catheters, stents, or other devices.
● Remove the guidewire carefully after the procedure.
PRODUCT APPLICATION
● Vascular Interventions: Used in angioplasty, stent placement, and other vascular procedures.
● Urological Procedures: Navigates through the urinary tract for stone removal or stent placement.
● Biliary and Pancreatic Interventions: Assists in accessing and treating blockages in the bile or pancreatic ducts.
● Gastrointestinal Procedures: Used in endoscopic retrograde cholangiopancreatography (ERCP) or other GI interventions.
● Neurological Interventions: Supports navigation in neurovascular procedures.
SPECIFICATIONS AND MODELS
| Product No | Model | Product No | Model |
| 156023 | 0.028inx150cm(J) | 158023 | 0.035inx150cm(J) |
| 156024 | 0.028inx150cm(S) | 158024 | 0.035inx150cm(S) |
| 156025 | 0.028inx180cm(J) | 158025 | 0.035inx180cm(J) |
| 156026 | 0.028inx180cm(S) | 158026 | 0.035inx180cm(S) |
| 156027 | 0.028inx260cm(J) | 158027 | 0.035inx260cm(J) |
| 156028 | 0.028inx260cm(S) | 158028 | 0.035inx260cm(S) |
| 157023 | 0.032inx150cm(J) | 159023 | 0.038inx150cm(J) |
| 157024 | 0.032inx150cm(S) | 159024 | 0.038inx150cm(S) |
| 157025 | 0.032inx180cm(J) | 159025 | 0.038inx180cm(J) |
| 157026 | 0.032inx180cm(S) | 159026 | 0.038inx180cm(S) |
| 157027 | 0.032inx260cm(J) | 159027 | 0.038inx260cm(J) |
| 157028 | 0.032inx260cm(S) | 159028 | 0.038inx260cm(S) |
Product Details
